Explosion-proof platform metal halide lamp

Applicable places

Suitable for flammable and explosive places roads and petrochemical plants, operations and offshore oil platform for fixed lighting use.

Performance characteristics

1.Excellent explosion-proof performance, can be flammable and explosive dangerous places safe and reliable work;

2.The use of high-intensity gas discharge lamp for light source, high luminous efficiency, high color rendering, color index> 90, through the fog is good, uniform illumination, the average life of up to 20,000 hours or more;

3.Shell selection of lightweight alloy materials and high-tech spray technology, can be in the long-term sun and rain and a variety of corrosive environments reliable use;

4.High reliability, low failure rate, easy maintenance;

5.Has a good electromagnetic compatibility, will not cause interference to the surrounding environment.

Technical Parameters

Rated voltage: AC220V 50HZ

Rated power: 250W 400W

Suitable light source: MH gas discharge lamp, HPS gas discharge lamp

Case protection: IP65

Corrosion grade: WF2

Insulation class: I

Thread thread: G3 / 4

Introduced cable: Φ8mm ~ Φ12mm

Dimensions: Φ446mm × 435mm (lamps)

            Φ310mm × 118mm (ballast)

Total weight: 7.3kg (lamps) 6.0kg (ballast box)

Explosion-proof mark: Exd II CT4 / T6
