LED Explosion -proof factory lamp

Explosion-proof energy-saving lamps 50W60W coal mine

  • Model
  • Brand
  • Specs

Product Description


[Applicable scope]

It is widely used in  oil drilling, oil refining, chemical industry, military industry and other dangerous environment and Marine oil platform, oil tankers and other places for general illumination lighting and assignments;

It is applicable for energy-saving reform projects and locations where are difficult to overhaul or    replace;

It is applicable for damp locations where have high protection requirements.

It is applicable for zone 1 and zone 2 in explosive gas atmosphere;

It is applicable for explosive gas atmosphere CAT. ⅡA ,ⅡB andⅡC ;

It is applicable for temperature groups T1-T6.



[technology parameters]

Type: GMD 210-B

Ex-mark: Exd II CT6

Input Voltage: AC/DC 220V±20% 50Hz

Rated Power:50W 60W 70W

Power Factor:0.98

Luminous Flux of LED: 4000~8500Lm

IP Grade :   IP66

Corrosion-proof Grade:WF2

Cable Entry: G3/4" in general, suitable for cables of Φ10mm~Φ14mm

Terminal block: wires≤2.5mm²

Installation :Ceiling/Bracket/Pendant/Wall30°/Fence/Flange mounting

Operating height: 4~ 6m

Mounting distance : 4~6m

Net Weight:7kg

Dimension:260x260x285
